Product Description
W3 Marchetti Dilatometer equipment
Product introduction:
This test has the functions and advantages of static cone penetration and side pressure test: the test is fast, accurate and economical. The test data has good reproducibility, small human influence factors, automatic data acquisition and storage, and automatic control of test signals. It is the first at home and abroad, and it has a data processing system (software) and two-way communication with it.
It can provide many important parameters of soil: lateral pressure coefficient Ko, pore water pressure U, undrained shear strength Cu, effective internal friction angle of sand Φ, bed reaction coefficient Kn, over-consolidation ratio OCR, compression modulus, Elastic modulus, shear modulus, division and naming of soil layers, compaction control, bulk density, judgment of sandy soil liquefaction... etc.
1. Penetration is generally pressed into the soil with a static cone penetrating machine, or into the soil with a dynamic penetrating hammer.
2. This test is suitable for all kinds of clay, silt and all kinds of sandy soil layers.
3. Using U disk storage and transmission, data transmission with the computer is more efficient and convenient.
Product main parameters:
1. Test probe: length 230-240mm, width 95mm, thickness 15mm;
2. Diameter of steel film: 60mm;
3. Rated air pressure: ;
4. Test depth: 0-50m (special stratum can be deepened); test spacing can be adjusted arbitrarily according to actual needs.
5. Indication error of the whole process: ±0.1%F.S
6. The number of test results storage holes is up to 9999.
7. Low power consumption, using rechargeable lithium battery, standby time up to 24 hours.
8. The measurement and control instrument is displayed as a liquid crystal display
9. Make data processing system (software) and its two-way communication
Detailed Photos
Product Parameters
| Test probe |
length 230-240mm, width 95mm, thickness 15mm; |
| Diameter of steel film |
60mm |
| Test depth |
: 0-50m |
| Indication error of the whole process |
±0.1%F.S |
| The number of test results storage holes |
up to 9999 |
Packaging & Shipping
Factory visiting
Lab display
Company Profile
Xi 'an Zealchon electronic technology co., LTD, located in new technology industry development zone in Xi'an, an ancient city in China. It covers an area of 7500 square meters of building area. Zealchen specialize in two aspects: one is civil engineering research and experimental apparatus; another is the semiconductor laser research and development. On one hand, currently based on civil experimental instrument research, the research team is founded by the personnel who come from Chang 'an university, Xi 'an polytechnic university, Xi 'an petroleum university, which has the top technology in this expertise. In addition, its research and development has accomplished a series of leading domestic and international standards, first-class technology of asphalt and asphalt mixture, road, bridge deck, geotechnical, structural testing instruments, even more, some of the products fill the blank of similar equipment at home and abroad, won national, ministerial, provincial awards. On-site manufacturing allows us to customize our products quickly and efficiently to meet specialized customer requests. Our technical support team, marketing, and web development teams make their homes in china as well, and are dedicated to providing comprehensive customer support and services.
